When installing sub metering systems in the UK, it is important to document specific details so that meters are configured correctly, provide accurate data and can be maintained effectively over time. Here’s a list of the minimum key information that should be recorded during the installation process:
Sub Metering Systems UK: General System Information
• Location Details: Record the exact location of each sub-meter, such as room, circuit, or equipment it is monitoring.
• Purpose of Meter: Specify what the sub-meter is measuring (e.g., lighting, HVAC, specific machinery, tenant usage).
• Meter Identification: Assign unique IDs or labels to each sub-meter for easy reference in the monitoring system.
Electrical Setup
• Voltage Configuration: Document whether the system is single-phase or three-phase and the nominal voltage level (e.g., 120V, 230V, 400V).
Current Transformers (CTs):
- Type and rating of CTs (e.g., 100A:5A, 400A:1A).
- Polarity and orientation of CT installation.
- Location and connection of CTs to the sub-meter.
Voltage Connections:
- Voltage tap points for each phase.
- Confirmation that connections are secure and meet manufacturer specifications.
Meter Configuration
Communication Settings:
- Protocol used (e.g., Modbus, BACnet, LoRaWAN).
- Address, baud rate, and parity for communication if applicable.
Measurement Settings:
- Configured current and voltage ratios.
- Power factor correction settings if required.
- Data Logging Interval: Record the interval at which the meter collects and transmits data (e.g., 1 minute, 15 minutes).
Integrating Sub Metering Systems
Connection to Monitoring System:
- Details of the gateway or data logger connecting the sub-meter to the monitoring platform.
- Verification that the sub-meter is successfully communicating with the system.
Integration Testing: Record results of initial tests to ensure the data is being logged accurately and displayed correctly.
Commissioning
Initial Readings: Capture the starting readings from the sub-meter at the time of installation.
Commissioning Report:
Confirm that the meter has been commissioned and verified for accurate operation.
Environmental and Physical Details
Mounting Details:
- Method of mounting (e.g., panel-mounted, DIN rail, wall-mounted).
- Accessibility for maintenance or data retrieval.
Protective Measures:
- Details of enclosures or protective covers, especially in industrial or outdoor installations.
Documentation and References
Wiring Diagrams: Provide detailed schematics showing how the sub-meter is connected to the system.
Manufacturer Specifications: Attach technical datasheets for reference.
Installation Photos: Take clear photographs of the installed meter
Contact Information: Record details of the installation team or technician for follow-up queries.
Why Is This Information Important?
Accurate Operation: Ensures the sub-meter is configured and installed correctly.
Troubleshooting: Simplifies maintenance and fault diagnosis in case of issues.
Regulatory Compliance: Provides documentation for audits or certifications.
System Expansion: Facilitates easier upgrades or integration of additional meters in the future.
By carefully documenting these details, you can ensure your sub-metering system operates effectively and provides reliable data over its lifespan.
